• NoEquMessage

Description:

Values: T (= yes),  F (= no)

Note: This value should not be changed


  • FatalErrorWarn

Description:

Values: T (= yes),  F (= no)

Note: This value should not be changed


  • VerkuerzteRohre

Description: Should shortened pipes be supported?

Values: T (= yes),  F (= no)


  • TStueckSprinkDB

Description:

Should tees be created at the sprinkler connections on the main pipe for the calculation?

0: never

1: always

2: only if a sprinkler supply pipe is in place

Values: 0, 1, 2


  • BogenAnPumpe

Description:

Should an elbow be created in a node if a pump has been added to that node?

If yes, place your pump as follows to enable the parameter:

Values: T (= yes),  F (= no)


  • VorgabeMaßstab

Description: Recommended value for the scale in new projects

Values: Integer greater than 0 / Default value 100 (1:100)


  • VorgabeStrangrohr

Description: The “branch pipe” option is selected as the default when entering sprinkler data

Values: T (= yes),  F (= no)


  • BerechnungsergebnisseKorrigieren

Description: Due to the iterative method used in the calculation, minor inaccuracies may occur in the calculation results. During the correction process, the calculated values for pressure loss, water flow, and flow velocity are corrected as follows.

If the respective value is less than 1/1000 of the maximum value (1/10,000 for pressure loss), then this value is set to 0.

Values: T (= yes),  F (= no)


  • NeueObjekteZuGruppe

Automatically assign new objects to the active group.

Default: Value 1

Newly drawn objects are automatically assigned to the active group. Value 0 disables this automatic assignment. New objects are not assigned to any group and are not connected to the network. Tip: Check which group new objects are assigned to.

  • Etagenverwaltung

Show or hide floor management in project management.

Floor management = 1 (default) - Floor management is visible in project management.

Value: 0 Floor management is not visible in project management.


  • RingleitungDurchgehendNummerieren

Ring circuits of pipes are assigned to the same group number, even if they do not run in the same direction.

Value 1: Default

Value 0: Disables the automatic assignment


  • Winkel_bis_DN

Create elbow threaded if the diameter of both pipes is less than or equal to “Winkel_bis_DN”; otherwise, an elbow is created. See also Elbows.

Default value: DN 50 – Elbows threaded are distributed up to and including DN50.
